Z-LINES
Z-LINES
Z-LINES
Z-LINES
Technical
Features
Four longitudinal linear grooves provide excellenthigh-speed performance and low noise performance
The application of tortuous thin grooves providesexcellent drainage and grip performance.
The rubber bump at the bottom of all grooveseffectively improves the self-cleaning property of the tire.
The wide shoulder design increases the rigidity of the tire shoulder and improves the wear resistance of the tire.

Spec

295/80R22.5
  • Loading Index154/149M
  • Overall Diameter(mm)1044
  • Overall Diameter(inch)41.1
  • PR18(J)
  • Section Width(mm)298
  • Section Width(inch)11.7
  • RM9
  • Tread Depth(mm)15
  • Tread Depth(32nd)18.9
  • Max.Load Single(kg)3750
  • Max.Load Single(lbs)8270
  • Max.Load Dual(kg)3250
  • Max.Load Dual(lbs)7160
  • Max. Pressure S(kpa)850
  • Max. Pressure S(psi)123
  • C A 71dB/A 3PMSF
315/70R22.5
  • Loading Index156/150L
  • Overall Diameter(mm)1014
  • Overall Diameter(inch)39.9
  • PR18(J)
  • Section Width(mm)312
  • Section Width(inch)12.3
  • RM9
  • Tread Depth(mm)15
  • Tread Depth(32nd)18.9
  • Max.Load Single(kg)4000
  • Max.Load Single(lbs)8820
  • Max.Load Dual(kg)3350
  • Max.Load Dual(lbs)7390
  • Max. Pressure S(kpa)900
  • Max. Pressure S(psi)130
  • C A 71dB/A 3PMSF
315/80R22.5
  • Loading Index156/150L (154/150M)
  • Overall Diameter(mm)1076
  • Overall Diameter(inch)42.4
  • PR20(L)
  • Section Width(mm)312
  • Section Width(inch)12.3
  • RM9
  • Tread Depth(mm)15
  • Tread Depth(32nd)18.9
  • Max.Load Single(kg)4000
  • Max.Load Single(lbs)8820
  • Max.Load Dual(kg)3350
  • Max.Load Dual(lbs)7390
  • Max. Pressure S(kpa)850
  • Max. Pressure S(psi)123
  • C A 71dB/A 3PMSF
12.00R24
  • Loading Index160/157K
  • Overall Diameter(mm)1226
  • Overall Diameter(inch)48.3
  • PR20PR
  • Section Width(mm)315
  • Section Width(inch)12.4
  • RM9
  • Tread Depth(mm)15
  • Tread Depth(32nd)18.5
  • Max.Load Single(kg)4500
  • Max.Load Single(lbs)9920
  • Max.Load Dual(kg)4125
  • Max.Load Dual(lbs)9090
  • Max. Pressure S(kpa)900
  • Max. Pressure S(psi)130
